## Econometrics using Matlab

### 1. Introduction

Matlab is a language particularly good at matrix computation. This makes it ideal for carrying out econometric estimations. This page gives a simple introduction on how to use Matlab.

First you will have to make a Tab-delimited data file, which we name "input.txt" and looks like this:

 1 0.39 1.88 2 0.29 2.88 3 0.19 3.88 4 0.09 4.88

Type:

Then there is variable "input" in memory, which is a matrix with 4 rows and 3 columns. We can assign columns of "input" to different variables:

 y = input(:, 2); x = input(:,3);

Now we have two more variables in memory, y and x,

x =

 0.39 0.29 0.19 0.09

y =

 1.88 2.88 3.88 4.88

### 3. Matrix Manipulation

The function "ones(m, n)" creates a matrix of ones with m rows and n columns. If n = 1, it is a vector of ones, which is useful in adding a constant to regressions. For example,

 X = [ones(4, 1)  x];

creats a new variable X, which is a matrix of 4 rows and 2 columns:

X=

 1 0.39 1 0.29 1 0.19 1 0.09

Note that the space between "ones(4,1)" and "x" is important, which denotes horizontal concatenation. If we use ";", which denotes vertical concatenation, we will get a different X which is a column vector with 8 elements.

### 4. Matrix Computation

The matrix-form econometric fomula can easily be translated into Matlab language. Take the familiar fomula of OLS estimator as an example:

The corresponding Matlab statement is:

beta_hat = inv(X' * X) * X' * y,

where inv(.) is a function that calculates inverse of a square matrix, ' denotes operation of "transpose", and * multiplication.

### 5. Save Results

To save results to a file on hard disk, the first thing to do is to specify a file to write to or create a new file. Both can be accomplished by:

 fid = fopen('filename.txt', 'w');

"fid" is a number, called the "handle" of the file, returned by the function fopen(). 'w' gains permission to write to the file, or create a new one if the file 'filename.txt' does not exist.

Then it is ready to write data to the file using function "fprintf()". For example, if we type

 fprintf(fid, '%3.2f   %3.2f\n', [x y]') ;
then the file "filename.txt" will look like this:
 0.39 1.88 0.29 2.88 0.19 3.88 0.09 4.88

'%3.2f   %3.2f\n' is called the "format string", which tells Matlab to write both x and y in the format of float number with total length of 3 and 2 digits in fraction.

In the end, we should close the file using the funtion "fclose()":

 fclose(fid);

### 6. An Example

Now we can estimate a classical regression model specified as:

or in matrix form,

,

#### 6.1 Data

Copy the following data into a text file, name it "input.txt". The 3th column corresponds to x, random numbers from a uniform distribution with range (0, 1). The second column corresponds to y, random numbers generated by

,

 1 1.02324 0.01964 2 2.36513 0.681277 3 1.7484 0.379481 4 2.67774 0.831796 5 1.99758 0.502813 6 2.42423 0.709471 7 1.85998 0.428892 8 1.60002 0.304617 9 1.3576 0.189654 10 1.38627 0.193431

#### 6.2 Code

Now we pretend not knowing a and b and estimate them from the data using OLS. Copy the following Matlab code into Matlab Editor,

 %%%%%work.m%%%%% % Load data and assign variables: load input.txt; y = input(:, 2); x = input(:, 3); n = length(x); X = [ones(n, 1) x]; % Regressor matrix m = 2; % Number of regressors % OLS estimate beta_hat = (X'*X)\X'*y; % Calculates regression statistics e = y - X*beta_hat; %Estimated disturbances sse = e'*e; %SSE (Sum of Square Errors) s2 = sse/(n - m); %Estimate of sigma square var = inv(X'*X)*s2; %Variance of the OLS estimate se = sqrt(diag(var)); %Standard Error of the estimates % Report results fid = fopen('output.txt', 'w'); fprintf(fid, '%f (%f)\n', [beta_hat se]'); fclose(fid); %%%%%%End of work.m%%%%%%

and type

 work ;

#### 6.3 Result

The output file "output.txt" looks like this:

 0.981432 (0.004195) 2.033886 (0.008550)

The estimated value of a is 0.981432 with a standard error of 0.004195, and the estimated value of b is 2.033886 with a standard error of 0.008550. Not bad!

### Other Resources

Always consult online documentation for help.

(Joe Junhui Qian 2004.09.08)
